System And Components
452-0303 MOUNTING GP-ENGINE FLEXIBLEPART OF 473-2866 INSTALLATION AR-ENGINE
Group No: 452-0303 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W9930 | 1 MOUNT AS | 1 | |
| 9W9953 | 2 SLEEVE | 3 | |
| 2737309 | 3 MOUNTING GP-ENGINE & XMSN | 3 | |
| 2837490 | 4 WASHER (51X100X8-MM THK) | 3 | |
| 4533047 | 5 PLATE | 1 | |
| 4533090 | 6 PLATE | 1 | |
| 4565203 | 7 WASHER | 1 | |
| 5227211 | 8 MOUNT AS | 1 | |
| 1102023 | STUD-WELD (M10X1.5X25-MM) | 2 | |
| 4592912 | 9 SUPPORT AS | 1 | |
| 1199880 | 10 BOLT (M12X1.25X30-MM) | 8 | |
| 1765311 | 11 LOCKNUT (M16X2-THD) | 3 | |
| 2852266 | 12 BOLT | 8 | |
| 5P1076 | 13 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 6V7688 | 14 LOCKNUT (M20X2.5-THD) | 1 | |
| 6V9167 | 15 BOLT (M20X2.5X140-MM) | 1 | |
| 7X0510 | 16 WASHER-HARD (15.5X29X3-MM THK) | 8 | |
| 7X0515 | 17 WASHER-HARD (17X35X5-MM THK) | 3 | |
| 8T4173 | 18 BOLT (M16X2X110-MM) | 3 | |
| 8T4184 | 19 BOLT (M12X1.75X45-MM) | 12 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T5439 | 21 WASHER-HARD (21.5X45X6-MM THK) | 1 | |
| 8T8549 | 22 LOCKNUT (M12X1.75-THD) | 12 | |
| 9W6582 | 23 SLEEVE | 1 | |
| 9W6584 | 24 WASHER (20.5X114X10-MM THK) | 1 | |
| 9W9952 | 25 WASHER (16.75X86X8-MM THK) | 3 | |
| 2916465 | 26 SEAL (15-CM) |
