System And Components
452-0316 RADIATOR GPPART OF 473-2866 INSTALLATION AR-ENGINE
Group No: 452-0316 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 1124159 | 2 MOUNTING AS | 2 | |
| 1558995 | 3 ADAPTER AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1559646 | SEAL | 1 | |
| 3779592 | ADAPTER | 1 | |
| 2066876 | 4 CAP-TUBE | 1 | |
| 2562057 | 5 MOUNT-RUBBER | 1 | |
| 2837520 | 6 RECOVERY GP-COOLANT | 1 | |
| 2840908 | CAP-UNVENTED | 1 | |
| 4548322 | 7 HOSE | 1 | |
| 4549533 | 8 HOSE | 1 | |
| 4599003 | 9 RADIATOR GP | 1 | |
| 1293180 | 10 LOCKNUT (M12X1.75-THD) | 2 | |
| 1P4278 | 11 CLAMP-HOSE | 3 | |
| 2459941 | 12 WASHER-HARD (12.2X55.1X3.2-MM THK) | 6 | |
| 2609235 | 13 VALVE AS-BALL | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609233 | VALVE-BALL | 1 | |
| 3T0852 | 14 LOCKNUT (M8X1.25-THD) | 5 | |
| 5P1076 | 15 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7Y7394 | 17 SCREW-BUTTON HEAD (M8X1.25X25-MM) | 3 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T6703 | 19 CLAMP-HOSE | 4 | |
| 8T4176 | 20 BOLT (M12X1.75X90-MM) | 2 | |
| 9X8258 | 21 WASHER (33X56X6-MM THK) | 2 | |
| 5P5991 | 22 HOSE (0.86-M) | ||
| 5P5991 | 22A HOSE (0.39-M) |
