System And Components
452-0319 AIR CLEANER GPS/N NRG1-UP
Group No: 452-0319 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2962735 | 1 INDICATOR AS-AIR FILTER CHANGE | 1 | |
| 4545767 | 2 HOSE | 1 | |
| 4545817 | 3 HOSE | 1 | |
| 4589377 | 4 AIR CLEANER GP | 1 | |
| 3620108 | FILTER ELEMENT-AIR (SECONDARY) | 1 | |
| 3534847 | VALVE-DUST | 1 | |
| 3620107 | FILTER ELEMENT-AIR (PRIMARY) | 1 | |
| 4615036 | COVER AS | 1 | |
| 4692205 | 5 BRACKET AS | 1 | |
| 4692214 | 6 SUPPORT-FILTER | 1 | |
| 4776106 | 7 SUPPORT-SENSOR | 1 | |
| 3T0852 | 8 LOCKNUT (M8X1.25-THD) | 5 | |
| 5P0597 | 9 CLAMP-HOSE | 1 | |
| 5P1076 | 10 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 6V5039 | 12 CLIP (SLOT) | 1 | |
| 6V5040 | 13 CLIP (TAB) | 1 | |
| 7X0818 | 14 BOLT (M8X1.25X45-MM) | 3 | |
| 7Y7394 | 15 SCREW-BUTTON HEAD (M8X1.25X25-MM) | 2 | |
| 8T4179 | 16 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4184 | 17 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4189 | 18 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4194 | 19 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T8549 | 21 LOCKNUT (M12X1.75-THD) | 2 | |
| 9M6738 | 22 CLAMP-HOSE | 1 | |
| 9M7959 | 23 CLAMP-HOSE | 2 | |
| 7K1181 | 24 STRAP-CABLE | 1 | |
| 3523966 | 25 CLIP (LADDER) | 1 | |
| 7X0579 | 26 WASHER-HARD (8.8X25.5X2-MM THK) | 2 |
