System And Components
473-6223 EXHAUST GPS/N NED1-UP; NTT1-UP
Group No: 473-6223 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4137 | 1 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4186 | 2 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4189 | 3 BOLT (M8X1.25X20-MM) | 5 | |
| 8T4908 | 5 BOLT (M8X1.25X25-MM) | 1 | |
| 5E9892 | 6 PIN | 2 | |
| 5P4116 | 7 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 6V7744 | 8 LOCKNUT (M10X1.5-THD) | 4 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 16 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 11 WASHER (6.6X12X2-MM THK) | 2 | |
| 1355049 | 12 CABLE AS | 2 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 3015155 | 13 TUBE | 1 | |
| 4749057 | 14 MUFFLER AS | 1 | |
| 4940216 | 15 SLEEVE | 1 | |
| 5241075 | 16 PIPE AS-EXHAUST | 1 | |
| 4939255 | 17 COVER | 1 | |
| 4692233 | 18 STACK AS | 1 | |
| 1076125 | HINGE AS | 1 | |
| 4749058 | 19 PLATE | 1 | |
| 4749060 | 20 PLATE | 1 | |
| 1303374 | 21 CLIP | 1 | |
| 3445673 | 22 NUT (M6X1-THD) | 1 | |
| 3445674 | 23 NUT (M8X1.25-THD) | 2 | |
| 8T6974 | 24 BOLT (M6X1X80-MM) | 1 | |
| 8T7547 | 25 BOLT (M8X1.25X30-MM) | 1 | |
| 2323121 | 26 NUT (M10X1.25-THD) | 4 | |
| 1984776 | 27 WASHER-HARD (8.8X20X8-MM THK) | 3 |
