System And Components
503-7890 GOVERNOR GPS/N NED1-UP; NTT1-UP
Group No: 503-7890 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3879887 | 1 BOLT-SOCKET HEAD | 2 | |
| 3879886 | 2 SOLENOID AS | 1 | |
| 3830214 | 3 SEAL-O-RING | 1 | |
| 3985521 | 4 PIN-SPRING | 2 | |
| 3932930 | 5 LEVER AS | 1 | |
| 3932927 | 6 LEVER AS | 1 | |
| 3932929 | 7 SPRING | 1 | |
| 3932932 | 8 PIN | 1 | |
| 3932933 | 9 PIN | 1 | |
| 3932926 | 10 SPRING | 1 | |
| 3932934 | 11 STUD | 1 | |
| 3830416 | 12 GASKET | 1 | |
| 3887540 | 13 COVER | 1 | |
| 3830198 | 14 NUT-FLANGE | 1 | |
| 3937570 | 15 BOLT-FLANGE HEAD | 3 | |
| 3887526 | 16 COVER | 1 | |
| 3887533 | 17 SPRING | 1 | |
| 3887536 | 18 NUT | 1 | |
| 5037891 | 19 LEVER AS | 1 | |
| 4151413 | WASHER | 1 | |
| 4151414 | RING-SNAP | 1 | |
| 4151415 | RING-SNAP | 1 | |
| 4151416 | RING-SNAP | 2 | |
| 3887532 | 20 SPRING | 1 | |
| 3887521 | 21 BOLT-ADJUSTMENT | 1 | |
| 3983277 | NUT | 1 | |
| 4151417 | SPRING | 1 | |
| 3830256 | 22 GASKET | 3 | |
| 3887527 | 23 BLOCK AS | 1 | |
| 3887528 | 24 NUT-FLANGE | 1 | |
| 3887534 | 25 GASKET | 1 | |
| 3932923 | 26 SLEEVE | 1 | |
| 3932950 | 27 SEAL-O-RING | 3 | |
| 3932925 | 28 LEVER AS | 1 | |
| 3887531 | 29 SHAFT | 1 | |
| 3932928 | 30 LEVER AS | 1 | |
| 3932924 | 31 HOUSING | 1 | |
| 3887535 | 32 BOLT-FLANGE HEAD | 6 | |
| 3937569 | 33 STUD | 2 | |
| 3932935 | 34 BOLT-ADJUSTMENT | 1 | |
| 3932936 | 35 BOLT-ADJUSTMENT | 1 | |
| 3830308 | 36 GASKET | 4 | |
| 3932951 | 37 NUT | 2 | |
| 3830317 | 38 CAP | 2 | |
| 3830195 | 39 NUT-HEX | 2 | |
| 3937581 | 40 BOLT | 2 | |
| 3937572 | 41 BOLT | 2 |
