System And Components
Assembly
100%

483-2686 LINES GP-FUELS/N NRG1-UP

Group No: 483-2686 · Commonality
Part NumberPart NameQty
7X25331 BOLT (M6X1X35-MM)4
8T41382 BOLT (M6X1X20-MM)6
8T41893 BOLT (M8X1.25X20-MM)2
8T42004 BOLT (M8X1.25X16-MM)3
8T49085 BOLT (M8X1.25X25-MM)3
3T08526 LOCKNUT (M8X1.25-THD)5
5P41167 WASHER-HARD (8.8X20.5X2-MM THK)5
7K11818 STRAP-CABLE10
8T42249 WASHER-HARD (8.8X16X2-MM THK)8
9P712110 STRAINER-FUEL1
9X825611 WASHER (6.6X12X2-MM THK)12
208846912 LOCKNUT (M6X1-THD)2
321861213 PLUG AS1
6V9508PLUG (11/16-16-THD)1
2287089SEAL-O-RING1
357739914 CAP GP-FUEL FILLER1
3497059CAP AS-FUEL (LOCKABLE, VENTED)1
3507735KIT-CAP FILTER (FUEL TANK)1
3641995BOOT-FUEL CAP1
363581815 FILTER GP-FUEL1
397930116 WASHER-HARD (11.5X20X15-MM THK)4
552553417 PUMP GP-FUEL TRANSFER1
1028802KIT-RECEPTACLE (2-PIN)1
4165884FILTER AS-FUEL (TRANSFER PUMP)1
457645618 TANK GP-FUEL1
476323019 SUPPORT AS1
6V9632NUT-WELD (M6X1-THD)4
7T1099LINK1
8T3612NUT-WELD (M8X1.25-THD)3
476323120 BRACKET1
483493321 BRACKET1
486446322 HOSE AS1
490728823 FLASHING1
099364924 BOLT (M8X1.25X40-MM)1
107474925 PLATE (TOP)(TOP)2
130530026 CLIP1
132578927 CLIP (LADDER)3
177221528 STRAP-DUAL CLAMP1
124627529 CLAMP-HOSE10
232249630 CLAMP-HALF4
352396631 CLIP (LADDER)1
4P758132 CLIP (LADDER)1
7X081833 BOLT (M8X1.25X45-MM)2
8F724234 WASHER (8.7X15.9X1.6-MM THK)8
8T217335 CONNECTOR-HOSE1
8T497036 BOLT (M6X1X14-MM)4
8T754737 BOLT (M8X1.25X30-MM)5
8C368138 HOSE-DRAIN (28-CM)
360561139 HOSE (137.5-CM)
360561139A HOSE (141-CM)
360561139B HOSE (115-CM)
360561139C HOSE (27-CM)
360561139D HOSE (6.8-CM)
