System And Components
458-9050 BOX GP-CONTROLPART OF 444-5383 BOX GP-CONTROL
Group No: 458-9050 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7R3029 | 1 CAP-DUST | 1 | |
| 3679470 | 2 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 3950256 | 3 SWITCH AS-HORN (PUSH BUTTON) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 4538890 | 5 MODULE GP-KEYPAD | 1 | |
| 5034452 | 6 PLATE | 2 | |
| 5026306 | 7 MOUNT AS | 1 | |
| 4589044 | 8 BOX GP-CONTROL | 1 | |
| 4589061 | 9 HARNESS AS-BOX | 1 | |
| 4790228 | 11 FILM-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 1554098 | 12 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 8 | |
| 3445673 | 13 NUT (M6X1-THD) | 4 | |
| 3C6969 | 14 NUT (M3X0.5-THD) | 8 | |
| 9X2042 | 15 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 4 |
