System And Components
439-0106 BOX GP-JUNCTION -LEFTPART OF 439-0096 BOX GP-JUNCTION
Group No: 439-0106 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3002101 | 1 TERMINAL | 2 | |
| 3014818 | 2 TERMINAL | 2 | |
| 3976851 | 3 WIRE AS (12-GA) | 1 | |
| 4257977 | 4 WIRE AS (12-GA) | 1 | |
| 4522869 | 5 CONNECTOR | 1 | |
| 4522870 | 6 HARNESS AS-WIRING (EXTENSION BOX, LH) | 1 | |
| 1127497 | END-WIRE (14-GA) | 3 | |
| 4338939 | RECEPTACLE (4-PIN) | 1 | |
| 4360366 | KIT-CAP | 1 | |
| 4522869 | CONNECTOR | 1 | |
| 4522895 | 7 BOX AS | 1 | |
| 0816373 | 8 SCREW-COUNTERSINK HEAD (M3X0.5X12-MM) | 2 | |
| 0966166 | 9 WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1214405 | 10 BOLT (M4X0.7X12-MM) | 1 | |
| 1235206 | 11 LOCKWASHER | 1 | |
| 1514977 | 12 WASHER (4.445X9.525X1.092-MM THK) | 1 | |
| 1H4393 | 13 LOCKWASHER | 1 | |
| 2878070 | 14 LOCK-CABLE | 2 | |
| 3911756 | 15 WASHER (3.3X9.5X1.6-MM THK) | 2 | |
| 3C6969 | 16 NUT (M3X0.5-THD) | 2 | |
| 5C8312 | 17 NUT (M4X0.7-THD) | 1 | |
| 6V5698 | 18 SCREW-BUTTON HEAD (M4X0.7X10-MM) | 1 | |
| 1735412 | 19 RAIL (7-CM) |
