System And Components
477-1970 BOX GP-JUNCTIONPART OF 444-5381 WIRING GP-HEATER
Group No: 477-1970 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2330059 | 1 FILM-WARNING (GROUND) | 1 | |
| 2869963 | 2 LATCH AS | 1 | |
| 2996863 | 3 CIRCUIT BREAKER (20-AMPERE) | 3 | |
| 3002101 | 4 TERMINAL | 4 | |
| 3013289 | 5 RELAY (12-VOLT) | 4 | |
| 3013291 | 6 TERMINAL | 1 | |
| 3723167 | 7 BOSS (M8X1.25X80-MM) | 4 | |
| 3914790 | 8 WIRE AS (12-GA) | 2 | |
| 4285998 | 9 WIRE AS-GROUND (16-GA) | 1 | |
| 4752526 | 10 RELAY (9-VOLT)(MONITOR) | 1 | |
| 4771969 | 11 BOX AS-ELECTRICAL | 1 | |
| 4771971 | 12 PLATE | 1 | |
| 4772445 | 13 PLATE | 1 | |
| 4772446 | 14 PAWL | 1 | |
| 4827793 | 15 TERMINAL | 1 | |
| 1A8912 | 16 WASHER (6.7X12.7X1.6-MM THK) | 16 | |
| 1H5089 | 17 LOCKWASHER | 4 | |
| 3445673 | 18 NUT (M6X1-THD) | 18 | |
| 3445674 | 19 NUT (M8X1.25-THD) | 3 | |
| 7H3937 | 20 LOCKWASHER | 4 | |
| 7X2619 | 21 BOLT (M6X1X10-MM) | 8 | |
| 8F7242 | 22 WASHER (8.7X15.9X1.6-MM THK) | 18 | |
| 8T4138 | 23 BOLT (M6X1X20-MM) | 2 | |
| 8T4200 | 24 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4970 | 25 BOLT (M6X1X14-MM) | 1 | |
| 8T7547 | 26 BOLT (M8X1.25X30-MM) | 3 | |
| 9D3721 | 27 SWITCH-TOGGLE (SINGLE POLE) | 1 | |
| 2177164 | 28 DUCT-WIRE (250-MM) | ||
| 2078643 | 29 DUCT-WIRE (220-MM EACH) | ||
| 1735412 | 30 RAIL (22-CM EACH) |
