System And Components
450-4701 WIRING GP-POWER RECEPTACLEPART OF 535-8850 DISTRIBUTION AR
Group No: 450-4701 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1588021 | 1 BOX (ELECTRICAL) | 1 | |
| 4263513 | 2 CIRCUIT BREAKER (16-AMPERE) | 1 | |
| 5216754 | 3 RECEPTACLE | 1 | |
| 5241087 | 4 COVER AS | 1 | |
| 4914064 | 5 HARNESS AS-AUXILIARY (110V) | 1 | |
| 1127497 | END-WIRE (14-GA) | 5 | |
| 1311497 | TERMINAL AS-RING (10-GA TO 12-GA) | 1 | |
| 2L8068 | TERMINAL-RING (10-GA TO 12-GA, 5/16-IN SCREW) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(4-CM) | ||
| 3293734 | TAPE-ELECTRICAL | ||
| 4914065 | 6 WIRE AS (110V) | 1 | |
| 4914066 | 7 WIRE AS (110V) | 1 | |
| 1514977 | 8 WASHER (4.445X9.525X1.092-MM THK) | 8 | |
| 5P8439 | 9 GROMMET | 1 | |
| 8T2659 | 10 LOCKNUT (M4X0.7-THD) | 6 | |
| 8T9405 | 11 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 2 | |
| 1748131 | 12 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 4 |
