System And Components
477-1828 MANIFOLD GP-HYDRAULICPART OF 477-1808 HYDRAULIC AR-AUXILIARY
Group No: 477-1828 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K2232 | 1 SPACER (11-MM THK) | 2 | |
| 1070003 | 2 MANIFOLD | 1 | |
| 1488431 | 3 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V8785 | TEE | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1536259 | 4 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8777 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1488308 | 5 ADAPTER AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 7X2470 | ADAPTER | 1 | |
| 1488335 | 6 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488340 | 7 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488352 | 8 ELBOW AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488364 | 9 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488370 | 10 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488374 | 11 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488408 | 12 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 7X0465 | 13 BOLT (M6X1X100-MM) | 2 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2416209 | 15 UNION AS-CROSS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1175208 | CROSS | 1 |
