System And Components
477-1822 VALVE & MTG GP-CONTROLIMPLEMENT VALVE
Group No: 477-1822 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T7910 | 1 ADAPTER | 1 | |
| 1649639 | 2 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1487925 | CONNECTOR | 1 | |
| 1649640 | 3 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1452237 | CONNECTOR | 1 | |
| 2416215 | 4 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 3447390 | 5 SENSOR GP-PRESSURE (HYDRAULIC OIL) | 1 | |
| 4414960 | 6 ELBOW AS | 1 | |
| 6V5330 | RING-RETAINING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3159849 | ELBOW | 1 | |
| 4530378 | SEAL-O-RING | 1 | |
| 4598196 | 7 VALVE GP-CONTROL (IMPLEMENT) | 1 | |
| 4602929 | 8 PLATE | 1 | |
| 1068715 | 9 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C8400 | ELBOW | 1 | |
| 1488325 | 10 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488327 | 11 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1626816 | 12 SEAL | 1 | |
| 1645567 | 13 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1662033 | 14 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X2444 | TEE-SWIVEL | 1 | |
| 2935203 | 15 ELBOW | 2 | |
| 3218672 | 16 CONNECTOR AS | 5 | |
| 6V0407 | SEAL-BONDED | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2935883 | CONNECTOR | 1 | |
| 3J1907 | 17 SEAL-O-RING | 1 | |
| 6V0852 | 18 CAP-DUST | 2 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4189 | 21 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 |
