System And Components
485-4596 VIBRATORY GPPART OF 444-5437, 444-5439 EXTENSION AR-SCREED
Group No: 485-4596 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2432636 | 1 KEY-RECTANGULAR (SQUARE) | 4 | |
| 4309329 | 2 VIBRATORY GP | 2 | |
| 4390074 | 3 COUPLING GP-TORSIONAL | 4 | |
| 4390075 | SLEEVE | 1 | |
| 4390076 | HUB | 2 | |
| 4853554 | 4 SHAFT | 2 | |
| 4887347 | 5 COVER AS | 4 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4887350 | 6 PLATE | 4 | |
| 0963001 | 7 SETSCREW-SOCKET (M5X0.8X6-MM) | 8 | |
| 8T4223 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4970 | 9 BOLT (M6X1X14-MM) | 12 | |
| 8T5001 | 10 BOLT (M12X1.75X130-MM) | 8 | |
| 9X8256 | 11 WASHER (6.6X12X2-MM THK) | 12 |
