System And Components
477-1817 LINES GP-PROPELS/N NED1-UP; NRG1-UP; NTT101-UP
Group No: 477-1817 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4807776 | 1 HOSE AS | 1 | |
| 4807782 | 2 HOSE AS | 1 | |
| 5146591 | 3 HOSE AS | 1 | |
| 5203334 | 4 HOSE AS | 1 | |
| 5019042 | 5 HOSE AS | 1 | |
| 5019043 | 6 HOSE AS | 1 | |
| 4835849 | 7 HOSE AS | 1 | |
| 4835850 | 8 HOSE AS | 1 | |
| 4900336 | 9 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 1788510 | PLATE-WELD | 1 | |
| 2042281 | 10 STRAP-CABLE | 5 | |
| 5P7466 | 11 CLIP (SLOT) | 2 | |
| 5P7467 | 12 CLIP (TAB) | 2 | |
| 5P8112 | 13 GROMMET | 2 | |
| 7G3832 | 14 GROMMET | 3 | |
| 7G3833 | 15 CLIP (TAB) | 3 | |
| 7G3834 | 16 CLIP (SLOT) | 3 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4189 | 18 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4179 | 19 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 5 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2006345 | 23 SADDLE-MOUNTING (DUAL SWIVEL) | 2 |
