450-4703 DEFLECTOR GPPART OF 444-5430 SCREED AR-FIXED

Group No: 450-4703 · Commonality
Part NumberPart NameQty
24643571 SCREW-FLAT HEAD (M10X1.5X60-MM)6
27119192 WASHER (17X30X4-MM THK)6
45060393 PLATE-RETAINER1
46691014 COVER AS (LH)1
46691025 COVER AS (RH)1
46691036 COVER AS (INSIDE, RH)1
46691047 COVER AS (INSIDE, LH)1
46696288 DEFLECTOR AS (EXTENDER, RH)1
46784459 DEFLECTOR AS (MAIN, RH)1
8T3490NUT-WELD (M10X1.5-THD)4
467845110 DEFLECTOR (EXTENDER, LH)1
467845511 DEFLECTOR AS (MAIN, LH)1
8T3490NUT-WELD (M10X1.5-THD)7
469221112 COVER (RIGHT)1
469221213 COVER (LEFT)1
7G883914 SPACER (13.5X57X6-MM THK)8
7X772915 WASHER (11X25X3-MM THK)31
8T413716 BOLT (M10X1.5X20-MM)11
8T418617 BOLT (M10X1.5X40-MM)4
8T419518 BOLT (M10X1.5X30-MM)16
8T412119 WASHER-HARD (11X21X2.5-MM THK)3
