System And Components
485-3958 GATE GP-END -LHPART OF 450-4718 GATE GP-END
Group No: 485-3958 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4589093 | 1 ADJUSTER GP-MANUAL (REAR) | 1 | |
| 2033977 | 2 LEVER | 1 | |
| 3098915 | 3 SPRING | 1 | |
| 3855389 | 4 BRACKET AS | 1 | |
| 4343826 | 5 ROD | 1 | |
| 4501885 | 6 SHOE AS (LH) | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 4853959 | 7 ADJUSTER GP-MANUAL (FRONT) | 1 | |
| 4853984 | 8 HANDRAIL AS (LH) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 5333660 | 9 ARM AS (LH) | 1 | |
| 4853993 | 10 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 5 | |
| 3558941 | NUT-WELD (M16X2-THD) | 3 | |
| 7P1695 | 11 WASHER (10.5X19X3-MM THK) | 10 | |
| 7X0515 | 12 WASHER-HARD (17X35X5-MM THK) | 3 | |
| 8T4179 | 13 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4186 | 14 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4197 | 15 BOLT (M8X1.25X40-MM) | 2 | |
| 8T4201 | 16 BOLT-LOCKING (M10X1.5X20-MM) | 8 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4779 | 18 BOLT (M16X2X35-MM) | 3 | |
| 2563561 | 19 CHAIN (30-CM EACH) |
