Assembly
100%

469-2202 PLATE & HEATER GP-SCREEDPART OF 488-7354 EXTENSION AR-SCREED

Group No: 469-2202 · Commonality
Part NumberPart NameQty
24899971 NUT-BRASS (M12X1.75-THD)16
43734442 PLATE GP-SCREED (FRONT)1
43734442A PLATE GP-SCREED (REAR)1
4194909STUD (M12X1.75X100-MM)4
4333174PLATE-SCREED1
43852153 PLATE-CLAMP2
5C72614 NUT (M8X1.25-THD)2
5P41165 WASHER-HARD (8.8X20.5X2-MM THK)2
8T68706 BOLT (M8X1.25X70-MM)2
