Assembly
100%

449-0410 PLATE GP-SCREEDPART OF 444-5430 SCREED AR-FIXED

Group No: 449-0410 · Commonality
Part NumberPart NameQty
22931381 SENSOR GP-TEMPERATURE (SCREED HEAT)4
9X1813SLEEVE (57-CM)
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1028802KIT-RECEPTACLE (2-PIN)1
43900782 PLATE-SENSOR4
32933563 NUT (M12X1.75-THD)88
43140584 PLATE AS-SCREED (EXTENDER, LH)1
4194909STUD (M12X1.75X100-MM)8
4314064PLATE-SCREED (EXTENDER, LH)1
43140605 PLATE AS-SCREED (EXTENDER, RH)1
4194909STUD (M12X1.75X100-MM)8
4330170PLATE-SCREED (EXTENDER, RH)1
43169376 PLATE AS-SCREED (MAIN)1
4194909STUD (M12X1.75X100-MM)20
4314063PLATE-SCREED (MAIN)1
43251197 PLATE-CLAMP4
43610498 COVER-SENSOR4
46922399 BAR-NOSE2
469224910 CLAMP12
469225911 BAR-NOSE2
480058412 SUPPORT AS8
8T3490NUT-WELD (M10X1.5-THD)4
172996613 BOLT (M12X1.75X65-MM)8
5C726114 NUT (M8X1.25-THD)12
6V883615 BOLT (M6X1X14-MM)8
5P411616 WASHER-HARD (8.8X20.5X2-MM THK)32
6V231617 BOLT (M8X1.25X12-MM)8
7D164918 WASHER-HARD (13.5X32X5-MM THK)16
7X772919 WASHER (11X25X3-MM THK)16
8T418520 BOLT (M10X1.5X50-MM)16
8T418921 BOLT (M8X1.25X20-MM)8
8T420022 BOLT (M8X1.25X16-MM)12
8T687023 BOLT (M8X1.25X70-MM)12
9X825624 WASHER (6.6X12X2-MM THK)8
5P824525 WASHER-HARD (13.5X25.5X3-MM THK)16
8T422326 WASHER-HARD (13.5X25.5X3-MM THK)36
8T422427 WASHER-HARD (8.8X16X2-MM THK)8
8K143328 GROMMET4
