System And Components
475-5190 BOGIE GPPART OF 475-5198, 475-5199 FRAME GP-TRACK ROLLER
Group No: 475-5190 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N5970 | 1 LOCKWASHER | 4 | |
| 9W5224 | 2 SEAL GP-DUO-CONE | 4 | |
| 8B7614 | 3 NUT-BEARING | 4 | |
| 4755192 | 4 FRAME-BOGIE | 1 | |
| 4755196 | 5 ROLLER GP-TRACK | 4 | |
| 3N6412 | 5A CONE-BEARING | 2 | |
| 3N6411 | 5B CUP-BEARING | 2 | |
| 4755193 | ROLLER AS | 1 | |
| 4755197 | 6 SHAFT | 2 | |
| 4755214 | 7 RETAINER | 4 | |
| 4755216 | 8 COVER AS | 4 | |
| 0541303 | 9 WASHER (40.46X69.85X7.37-MM THK) | 4 | |
| 3J3679 | 10 PLUG AS | 4 | |
| 1J9671 | SEAL-O-RING | 1 | |
| 9S8003 | PLUG (1/2-20-THD) | 1 | |
| 9X2043 | 11 SCREW-TRUSS HEAD (M6X1X14-MM) | 28 |
