System And Components
475-5200 TENSIONER GP-TRACKPART OF 475-5198, 475-5199 FRAME GP-TRACK ROLLER
Group No: 475-5200 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8488 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3638786 | 2 PIN-CLEVIS | 1 | |
| 4755195 | 3 CYLINDER GP-HYDRAULIC | 1 | |
| 4912134 | RETAINER-RING | 1 | |
| 4755201 | 4 SHAFT-IDLER | 1 | |
| 4755204 | 5 TIRE AS | 2 | |
| 4755208 | 6 PIN | 1 | |
| 4755209 | 7 TUBE AS | 1 | |
| 4755215 | 8 SHIM (0.51-MM THK) | 4 | |
| 4755217 | 9 BUSHING | 2 | |
| 4755219 | 10 PLATE | 2 | |
| 4755220 | 11 PLATE | 2 | |
| 4755222 | 12 HUB GP-ROLLER | 2 | |
| 4755224 | 13 SHIM (0.05-MM THK) | 6 | |
| 4755225 | 14 SHIM (0.13-MM THK) | 6 | |
| 4755226 | 15 SHIM (0.18-MM THK) | 6 | |
| 3B4629 | 16 PIN-COTTER | 1 | |
| 4H6996 | 17 PIN-SPRING | 1 | |
| 9X2043 | 18 SCREW-TRUSS HEAD (M6X1X14-MM) | 12 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4183 | 20 BOLT (M12X1.75X40-MM) | 20 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 9F2247 | 23 PLUG-PIPE (1/8-27-THD) | 2 | |
| 4912135 | KIT-SEAL | 1 |
