System And Components
478-4039 BLADE & MOUNTING GPAN ATTACHMENT
Group No: 478-4039 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1355049 | 1 CABLE AS | 2 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 3682348 | 2 PIN-LOCK | 2 | |
| 4850254 | 3 BRACKET AS | 2 | |
| 4850255 | 4 BRACKET AS | 2 | |
| 4850256 | 5 BRACKET AS | 2 | |
| 4850257 | 6 BRACKET AS | 1 | |
| 1022868 | GRIP-HANDLE | 1 | |
| 4850258 | 7 FLASHING | 2 | |
| 4850259 | 8 PLATE | 2 | |
| 4850321 | 9 BRACKET AS | 1 | |
| 1022868 | GRIP-HANDLE | 1 | |
| 3293356 | 10 NUT (M12X1.75-THD) | 6 | |
| 7X2621 | 11 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4122 | 12 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 8T4194 | 13 BOLT (M12X1.75X50-MM) | 6 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4778 | 15 LOCKNUT (M16X2-THD) | 8 | |
| 8T6385 | 16 BOLT (M16X2X180-MM) | 8 | |
| 8T7338 | 17 BOLT (M16X2X45-MM) | 8 | |
| 9X8257 | 18 WASHER (17.5X30X3.5-MM THK) | 16 |
