System And Components
488-1422 EXTENSION GP-SCREEDPART OF 444-5439 EXTENSION AR-SCREED
Group No: 488-1422 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3109823 | 1 ADJUSTER GP-MANUAL | 2 | |
| 5031485 | 2 COVER AS (RH) | 1 | |
| 5031478 | 3 GATE AS | 2 | |
| 5031484 | 4 COVER AS (LH) | 1 | |
| 6V7687 | 5 LOCKNUT (M12X1.75-THD) | 4 | |
| 7G8839 | 6 SPACER (13.5X57X6-MM THK) | 4 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 8 NUT (M10X1.5-THD) | 4 | |
| 8T4139 | 9 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4195 | 10 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4223 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 4 |
