System And Components
368-2215 LINES GP-AIR -ATAACS/N N9S1-UP
Group No: 368-2215
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 1 | |
| 1296400 | 2 ADAPTER | 1 | |
| 2011260 | 3 HOSE | 1 | |
| 2840671 | 4 CLAMP-BAND | 1 | |
| 3072671 | 5 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3255465 | 6 HOSE-ELBOW | 1 | |
| 3453816 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 3523698 | 8 ELBOW-AIR | 1 | |
| 3682242 | 9 TUBE AS | 1 | |
| 3682263 | 10 TUBE AS | 1 | |
| 3682269 | 11 HOSE-REDUCER | 2 | |
| 4934522 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1984777 | 13 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 2126932 | 14 CLAMP-T BOLT | 1 | |
| 2094579 | 15 CLAMP | 6 | |
| 2162211 | 16 CLAMP | 1 | |
| 2276715 | 17 STUD (M10X1.5X30-MM) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4123 | 19 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 21 BOLT (M10X1.5X35-MM) | 2 | |
| 8T5460 | 22 BOLT (M20X2.5X40-MM) | 2 | |
| 9X2646 | 23 CLIP (SLOT) | 1 | |
| 9X2647 | 24 CLIP (TAB) | 1 | |
| 9X6400 | 25 CLIP-HALF | 2 | |
| 8C3089 | 26 SEAL-O-RING | 1 |
