System And Components
253-9814 EXCITER GP -PERMANENT MAGNETS/N G3A1-UP; G1B1-UP; G1F1-UP; G1H1-UP; G2L1-UP; G2Y1-UP
Group No: 253-9814
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C8478 | 1 BOLT (M20X2.5X140-MM) | 1 | |
| 8T2229 | 2 WASHER-BELLEVILLE | 4 | |
| 8T2947 | 3 BOLT (M6X1X45-MM) | 4 | |
| 0815553 | 4 WASHER | 1 | |
| 1085749 | 5 ROTOR (MAGNETIC) | 1 | |
| 2533525 | 6 STATOR AS-MAGNET | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2539817 | 7 SHAFT | 1 | |
| 2539818 | 8 WASHER-SPECIAL | 1 |
