System And Components
397-1796 MOUNTING GP-INSTRUMENT PANELS/N E2N1-UP; E2T1-UP
Group No: 397-1796
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W8129 | 1 SUPPORT | 1 | |
| 6L9447 | 2 WASHER | 2 | |
| 3209696 | 3 WIRE AS | 1 | |
| 3971788 | 4 BRACKET | 1 | |
| 3971789 | 5 BRACKET | 1 | |
| 3971797 | 6 BRACKET | 1 | |
| 3971799 | 7 BRACKET | 1 | |
| 3971800 | 8 BRACKET | 1 | |
| 3971801 | 9 BRACKET | 2 | |
| 4226771 | 10 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 21 | |
| 9D6621 | NUT-WELD (10-24-THD) | 3 | |
| 0S1585 | 11 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 5 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 8 | |
| 1A5964 | 14 BOLT (3/8-16X4.5-IN) | 2 | |
| 1D4538 | 15 BOLT (5/16-18X2.25-IN) | 1 | |
| 2A4639 | 16 BOLT (3/8-16X1.625-IN) | 1 | |
| 2B2694 | 17 BOLT (5/16-18X2-IN) | 5 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 7 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5S0003 | 21 NUT (5/16-18-THD) | 6 | |
| 6H1717 | 22 BOLT (1/2-13X1.125-IN) | 1 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8413 | 24 WASHER-RETAINING (0.344X1.5X0.23-IN THK) | 6 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 9 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 16 | |
| 9Y9481 | 27 WASHER (9.9X47.8X1.5-MM THK) | 6 | |
| 2H3855 | 28 BOLT (1/2-13X0.875-IN) | 1 |
