System And Components
Assembly
100%

477-7960 BULLDOZER GP -BACKWALLS/N L9F1-UP

Group No: 477-7960
Part NumberPart NameQty
47402841 PLATE-RUBBER2
47402883 PLATE-RUBBER1
47402894 PLATE-RUBBER1
47402756 BEARING-SLEEVE4
47402767 BEARING-SLEEVE4
47402778 BEARING-SLEEVE2
47402789 PIN2
474028011 PLATE-COVER2
474029017 COVER AS2
474029118 PLATE AS2
478133019 BULLDOZER AS-WEAR (BACKWALL)1
480661320 BEARING2
491330321 CYLINDER & LINES GP-BUCKET1
492659922 PIN AS2
312569423 SETSCREW (1/4-20X0.25-IN)1
6V442924 BOLT (M16X2X40-MM)14
6V584425 BOLT (M16X2X35-MM)20
7X056426 WASHER-HARD (20X51X3-MM THK)2
7X255227 BOLT (M16X2X30-MM)46
8D505428 WASHER-HARD (17X30X3-MM THK)80
8T065129 BOLT (M20X2.5X30-MM)2
8T412130 WASHER-HARD (11X21X2.5-MM THK)8
8T419531 BOLT (M10X1.5X30-MM)8
4894305LUBRICATION GP-AUTOMATIC1
