472-5471 BULLDOZER GP -BACKWALLS/N P6J1-UP; A8Z1-UP

Group No: 472-5471
Part NumberPart NameQty
47254721 PLATE2
47254742 PLATE1
47254753 PLATE1
10645504 BEARING-ALIGNING (180-MM ID)2
15911195 LOCKWASHER8
44021117 PIN2
44021268 PLATE-CAP2
44393109 PLATE AS2
443931510 PLATE AS1
443932111 PLATE AS1
444143612 PIN2
444143713 PIN2
444144014 BUSHING4
444144115 BUSHING4
444144216 PLATE4
444144317 PLATE-COVER2
444144518 PLATE-COVER2
444144619 PLATE2
444144720 PLATE-STRIP2
472547022 BULLDOZER AS-WEAR (BACKWALL)1
472547723 PLATE-STRIP2
480741824 COVER AS1
480741925 COVER AS1
486103426 BEARING-SLEEVE2
487819127 CYLINDER & LINES GP-BUCKET1
103809628 RING-RETAINING4
312569429 SETSCREW (1/4-20X0.25-IN)1
7X255230 BOLT (M16X2X30-MM)16
7X256231 BOLT (M20X2.5X45-MM)6
8T412332 WASHER (22X35X3.5-MM THK)14
8T419033 BOLT (M16X2X25-MM)36
8T419334 BOLT (M16X2X50-MM)12
8T491035 BOLT (M12X1.75X60-MM)8
8T546036 BOLT (M20X2.5X40-MM)8
9X825737 WASHER (17.5X30X3.5-MM THK)64
4546178LUBRICATION GP-AUTOMATIC1
