Assembly
100%

490-8974 BULLDOZER GP -BACKWALLS/N P6J1-UP; A8Z1-UP

Group No: 490-8974
Part NumberPart NameQty
50084941 PLATE1
50084952 PLATE1
50084963 PLATE2
10645504 BEARING-ALIGNING (180-MM ID)2
15911195 LOCKWASHER8
9X82576 WASHER (17.5X30X3.5-MM THK)64
44021117 PIN2
44021268 PLATE-CAP2
44393109 PLATE AS2
443931510 PLATE AS1
443932111 PLATE AS1
444143612 PIN2
444143713 PIN2
444144014 BUSHING4
444144115 BUSHING4
444144216 PLATE4
444144317 PLATE-COVER2
444144518 PLATE-COVER2
444144619 PLATE2
444144720 PLATE-STRIP2
472547722 PLATE-STRIP2
486103423 BEARING-SLEEVE2
487819124 CYLINDER & LINES GP-BUCKET1
500849325 BULLDOZER AS-WEAR (BACKWALL)1
500849726 PLATE-COVER2
103809627 RING-RETAINING4
312569428 SETSCREW (1/4-20X0.25-IN)1
7X255229 BOLT (M16X2X30-MM)16
7X256230 BOLT (M20X2.5X45-MM)6
8T412331 WASHER (22X35X3.5-MM THK)14
8T419032 BOLT (M16X2X25-MM)36
8T419333 BOLT (M16X2X50-MM)12
8T491034 BOLT (M12X1.75X60-MM)8
8T546035 BOLT (M20X2.5X40-MM)8
4546178LUBRICATION GP-AUTOMATIC1
