System And Components
467-1599 CYLINDER GP-HYDRAULICS/N P6J1-UP; A8Z1-UP
Group No: 467-1599
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6381 | 1 BOLT (M20X2.5X120-MM) | 11 | |
| 5221530 | 2 CYLINDER AS | 1 | |
| 4671613 | 3 HEAD | 1 | |
| 4671614 | 4 YOKE | 1 | |
| 4671615 | 5 FLANGE | 1 | |
| 4671617 | 6 ROD-PISTON | 1 | |
| 4711978 | 7 BUSHING | 2 | |
| 4806611 | 8 BEARING-ALIGNING | 1 | |
| 4833696 | 9 RING-RETAINING | 1 | |
| 4876607 | 10 WASHER (21X37X4-MM THK) | 11 | |
| 4876626 | 11 BOLT-12 POINT HEAD (M27X2X140-MM) | 10 | |
| 4921758 | 12 PIN-DOWEL | 1 | |
| 4941786 | 13 SEAL-O-RING | 1 | |
| 4941787 | 14 SEAL | 2 | |
| 4941788 | 15 RING-WEAR | 1 | |
| 4941789 | 16 RING-WEAR | 1 | |
| 4941790 | 17 SEAL-PISTON | 1 | |
| 4941792 | 18 RING-BACKUP | 1 | |
| 4941793 | 19 RING-WEAR | 1 | |
| 4941794 | 20 SEAL-WIPER | 1 | |
| 4941795 | 21 SEAL-WIPER | 1 | |
| 4941796 | 22 RING-WEAR | 1 | |
| 4941797 | 23 SEAL-BUFFER | 2 | |
| 5065758 | 24 SEAL-O-RING | 1 | |
| 4671604 | KIT-SEAL (HYDRAULIC CYLINDER) | 1 |
