System And Components
522-1531 CYLINDER GP-HYDRAULICS/N P6J1-UP; A8Z1-UP
Group No: 522-1531
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4592029 | 1 ROD-PISTON | 1 | |
| 4640773 | 2 HEAD | 1 | |
| 4640777 | 3 FLANGE | 1 | |
| 4649573 | 4 RING-WEAR | 1 | |
| 4649574 | 5 SEAL-PISTON | 1 | |
| 4649587 | 6 RING-WEAR | 1 | |
| 4671614 | 7 YOKE | 1 | |
| 4711978 | 8 BUSHING | 2 | |
| 4806611 | 9 BEARING-ALIGNING | 1 | |
| 4853770 | 10 BOLT-HEAD | 11 | |
| 4876608 | 11 WASHER (23X39X4-MM THK) | 11 | |
| 4876626 | 12 BOLT-12 POINT HEAD (M27X2X140-MM) | 10 | |
| 4921758 | 13 PIN-DOWEL | 1 | |
| 4941786 | 14 SEAL-O-RING | 1 | |
| 4941801 | 15 RING-BACKUP | 1 | |
| 4941802 | 16 SEAL-WIPER | 1 | |
| 4941803 | 17 SEAL | 1 | |
| 4941804 | 18 SEAL | 1 | |
| 4941805 | 19 RING-WEAR | 3 | |
| 5065759 | 20 SEAL-O-RING | 1 | |
| 5221532 | 21 CYLINDER AS | 1 | |
| 0915013 | 22 RING | 1 | |
| 4640764 | KIT-SEAL (HYDRAULIC CYLINDER) | 1 |
