System And Components
508-4197 LUBRICATION GP-AUTOMATICS/N P6J1-UP; A8Z1-UP
Group No: 508-4197
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1759489 | 1 FITTING AS | 4 | |
| 1254984 | 2 CLAMP | 6 | |
| 2132265 | 3 UNION AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1500128 | UNION | 1 | |
| 3703474 | 4 UNION AS | 4 | |
| 4370899 | 5 CLAMP | 4 | |
| 4406509 | 6 ADAPTER AS | 2 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3866212 | ADAPTER | 1 | |
| 4512766 | SEAL | 1 | |
| 4488983 | 7 ADAPTER AS | 18 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3960392 | ADAPTER | 1 | |
| 4512762 | SEAL | 1 | |
| 4510393 | 8 PLUG AS | 6 | |
| 3849219 | PLUG | 1 | |
| 4512762 | SEAL | 1 | |
| 4510428 | 9 ADAPTER AS | 18 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4510427 | ADAPTER | 1 | |
| 4515682 | SEAL | 1 | |
| 4511739 | 10 ADAPTER AS | 6 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 4696943 | 11 BLOCK AS | 2 | |
| 4696946 | 12 ADAPTER | 10 | |
| 4696947 | 13 ADAPTER | 6 | |
| 4696954 | 14 VALVE AS-CHECK | 24 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4710693 | VALVE-CHECK | 1 | |
| 4733071 | 15 PLUG | 2 | |
| 4828201 | 16 TUBE AS | 2 | |
| 4921227 | 17 BLOCK AS | 4 | |
| 4965282 | 18 BLOCK AS | 1 | |
| 5083157 | 19 HOSE AS | 4 | |
| 5083158 | 20 HOSE AS | 4 | |
| 5083159 | 21 HOSE AS | 2 | |
| 5083160 | 22 HOSE AS | 2 | |
| 5083161 | 23 HOSE AS | 2 | |
| 5083162 | 24 HOSE AS | 2 | |
| 5083163 | 25 HOSE AS | 2 | |
| 5083164 | 26 HOSE AS | 2 | |
| 5083165 | 27 HOSE AS | 2 | |
| 5083168 | 28 HOSE AS | 2 | |
| 5083169 | 29 HOSE AS | 2 | |
| 5083170 | 30 HOSE AS | 2 | |
| 5083171 | 31 HOSE AS | 2 | |
| 5083172 | 32 HOSE AS | 2 | |
| 5083177 | 33 HOSE AS | 2 | |
| 5083178 | 34 HOSE AS | 2 | |
| 5083179 | 35 TUBE AS | 2 | |
| 1074749 | 36 PLATE | 26 | |
| 1556345 | 37 UNION AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8740 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1964204 | 38 BOLT (M6X1X40-MM) | 12 | |
| 2287089 | 39 SEAL-O-RING | 4 | |
| 2322496 | 40 CLAMP-HALF | 64 | |
| 2815930 | 41 REDUCER AS | 2 | |
| 6V8946 | REDUCER | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2977976 | 42 ELBOW AS | 4 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3353971 | 43 TEE AS | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 1488445 | 44 TEE AS | 2 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9847 | TEE-SWIVEL | 1 | |
| 4357441 | 45 PLATE-COVER | 4 | |
| 6V5220 | 46 BOLT (M8X1.25X65-MM) | 14 | |
| 6V9168 | 47 NUT (11/16-16-THD) | 8 | |
| 6V9829 | 48 CAP (ORFS) | 4 | |
| 6V9833 | 49 CAP | 2 | |
| 7X2533 | 50 BOLT (M6X1X35-MM) | 52 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 8T6466 | 52 BOLT (M10X1.5X60-MM) | 8 | |
| 9U7123 | 53 CAP | 4 | |
| 1439607 | 54 STRAP-CABLE | 2 | |
| 4391987 | 55 UNION AS | 2 | |
| 6V8734 | UNION | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 5215816 | 56 ADAPTER AS | 2 | |
| 2287093 | SEAL-O-RING | 1 | |
| 5215815 | ADAPTER-STR | 1 |
