System And Components
Assembly
100%

423-1411 BOWL GP -CLAMS/N A321-UP

Group No: 423-1411
Part NumberPart NameQty
41756211 PIN2
41756222 PLATE-COVER4
41756233 BUSHING4
41756244 BUSHING4
42314255 KIT-BLOCK2
42314266 BOWL AS-WEAR1
42315347 ADAPTER6
42315358 LOCK-WEDGE6
42315369 TIP-ABRASION6
423153810 PIN-RETAINER6
423154011 RING-RETAINER6
423154412 SHROUD (CENTER)1
423154613 SHROUD (LH)2
423154714 SHROUD (RH)2
423155015 KIT-RETAINER2
423155116 PROTECTOR-SIDE BAR1
423155217 PROTECTOR-SIDE BAR1
423155318 PROTECTOR2
423155719 KIT-RETAINER2
423155920 KIT-RETAINER5
423156021 KIT-BLOCK2
7X256322 BOLT (M20X2.5X60-MM)12
8T412323 WASHER (22X35X3.5-MM THK)12
