System And Components
Assembly
100%

435-0858 BOWL GP -CLAMS/N A321-UP

Group No: 435-0858
Part NumberPart NameQty
8T41231 WASHER (22X35X3.5-MM THK)12
41756212 PIN2
41756223 PLATE-COVER4
41756234 BUSHING4
41756245 BUSHING4
42315346 ADAPTER6
42315357 LOCK-WEDGE6
42315368 TIP-ABRASION6
42315389 PIN-RETAINER6
423154010 RING-RETAINER6
423154411 SHROUD (CENTER)1
423154612 SHROUD (LH)2
423154713 SHROUD (RH)2
423155014 KIT-RETAINER2
423155115 PROTECTOR-SIDE BAR1
423155216 PROTECTOR-SIDE BAR1
423155317 PROTECTOR2
423155718 KIT-RETAINER2
423155919 KIT-RETAINER5
435085720 BOWL AS1
435406721 KIT-BLOCK1
312569422 SETSCREW (1/4-20X0.25-IN)1
7X256323 BOLT (M20X2.5X60-MM)12
