418-7446 BULLDOZER GP -BACKWALLS/N BP41-UP

Group No: 418-7446
Part NumberPart NameQty
9X82571 WASHER (17.5X30X3.5-MM THK)104
41874493 BUSHING2
41874504 BUSHING4
41874515 BUSHING4
41874526 BUSHING4
41874537 PIN2
41874548 PIN2
41874579 COVER AS2
418745810 PLATE-COVER2
418745911 PLATE-COVER2
418746012 PLATE-COVER2
418746113 PLATE-COVER2
418746314 BRACKET AS1
418746415 PLATE-COVER2
418746516 PLATE-COVER2
418746617 PLATE-COVER1
418746718 PLATE-COVER2
418746819 PLATE2
418746920 PLATE2
418747021 PLATE2
418747122 PLATE-COVER2
418747223 BULLDOZER AS-WEAR (BACKWALL)1
424415624 PLATE-COVER2
451983725 PLATE-COVER2
480550026 COVER GP (CLOSING)2
2892270SEAL-O-RING1
4812868PLATE AS-COVER1
312569428 SETSCREW (1/4-20X0.25-IN)1
7X255229 BOLT (M16X2X30-MM)12
7X255330 BOLT (M16X2X40-MM)72
8T066631 BOLT (M24X3X90-MM)12
8T416732 WASHER-HARD (26X44X4-MM THK)12
8T419333 BOLT (M16X2X50-MM)28
4187448CYLINDER & LINES GP-BUCKET1
5118655LUBRICATION GP-AUTOMATIC1
