Assembly
100%

480-1504 CYLINDER & LINES GP-BUCKETS/N BP41-UP

Group No: 480-1504
Part NumberPart NameQty
2T30001 FLANGE-SPLIT32
12442892 FLANGE-SPLIT4
23524763 SEAL-RECTANGULAR16
43844244 DISTRIBUTOR GP1
43844255 CYLINDER GP-HYDRAULIC2
47970006 BLOCK4
48054757 HOSE AS2
48054768 HOSE AS2
48054789 HOSE AS1
480547910 HOSE AS1
481998811 HOSE AS1
481998912 HOSE AS1
490280613 FLANGE1
154158014 WASHER-HARD (22X38X6-MM THK)8
235248015 SEAL-RECTANGULAR3
5P005016 COVER2
6V856917 BOLT (M20X2.5X200-MM)4
7X256318 BOLT (M20X2.5X60-MM)4
7X256519 BOLT (M20X2.5X100-MM)4
7Y521620 BOLT-SOCKET HEAD (M20X2.5X80-MM)8
8T412221 WASHER-HARD (17X32X3.5-MM THK)64
8T412322 WASHER (22X35X3.5-MM THK)12
8T414023 BOLT (M16X2X60-MM)64
