System And Components
480-1503 LUBRICATION GP-AUTOMATICS/N BP41-UP
Group No: 480-1503
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6K0806 | 1 STRAP-CABLE | 20 | |
| 4377519 | 2 UNION | 24 | |
| 4377520 | 3 UNION | 2 | |
| 4377521 | 4 FERRULE | 8 | |
| 4377522 | 5 UNION | 2 | |
| 4377523 | 6 LOCKNUT | 10 | |
| 4377524 | 7 TEE | 2 | |
| 6V5220 | 8 BOLT (M8X1.25X65-MM) | 16 | |
| 4377528 | 9 UNION | 16 | |
| 4377529 | 10 ELBOW | 28 | |
| 4377530 | 11 REDUCER | 2 | |
| 4377531 | 12 TEE | 4 | |
| 4377532 | 13 UNION | 8 | |
| 4377533 | 14 WASHER | 16 | |
| 4696946 | 15 ADAPTER | 12 | |
| 4696947 | 16 ADAPTER | 2 | |
| 4733071 | 17 PLUG | 32 | |
| 4377537 | 18 UNION | 24 | |
| 4377538 | 19 ELBOW | 8 | |
| 4663435 | 20 PLUG-SCREW | 8 | |
| 4377540 | 21 CLAMP AS | 6 | |
| 4377541 | 22 CLAMP AS | 4 | |
| 4377542 | 23 CLAMP AS | 32 | |
| 4377543 | 24 UNION | 8 | |
| 4377595 | 25 CAP | 4 | |
| 4377596 | 26 CAP | 24 | |
| 4377597 | 27 BLOCK-MANIFOLD | 2 | |
| 4377598 | 28 BLOCK-MANIFOLD | 2 | |
| 4377601 | 29 BLOCK-MANIFOLD | 4 | |
| 4875766 | 30 ADAPTER | 2 | |
| 4916100 | 31 HOSE AS | 4 | |
| 4916102 | 32 HOSE AS | 2 | |
| 4916103 | 33 HOSE AS | 2 | |
| 4916104 | 34 HOSE AS | 2 | |
| 4916105 | 35 HOSE AS | 4 | |
| 4916107 | 36 HOSE AS | 4 | |
| 4916109 | 37 HOSE AS | 2 | |
| 4916110 | 38 HOSE AS | 2 | |
| 4916114 | 39 HOSE AS | 2 | |
| 4916116 | 40 HOSE AS | 2 | |
| 4916117 | 41 HOSE AS | 2 | |
| 4916118 | 42 HOSE AS | 2 | |
| 4916119 | 43 HOSE AS | 2 | |
| 4916121 | 44 HOSE AS | 4 | |
| 4916123 | 45 HOSE AS | 2 | |
| 4916124 | 46 HOSE AS | 2 | |
| 4916125 | 47 HOSE AS | 2 | |
| 4917147 | 48 TUBE | 2 | |
| 4917148 | 49 TUBE | 1 | |
| 4917149 | 50 TUBE | 1 | |
| 4920744 | 51 PLUG | 2 | |
| 1617632 | 52 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 4 | |
| 2416158 | 53 PLUG | 2 | |
| 3445675 | 54 NUT (M10X1.5-THD) | 4 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 9U7123 | 56 CAP | 10 |
