System And Components
509-3257 LUBRICATION GP-AUTOMATICS/N BP41-UP
Group No: 509-3257
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1055212 | 1 PLUG AS | 2 | |
| 8T6850 | SEAL-O-RING | 1 | |
| 2416158 | PLUG | 1 | |
| 6K0806 | 2 STRAP-CABLE | 20 | |
| 3703474 | 3 UNION AS | 8 | |
| 4370899 | 4 CLAMP | 6 | |
| 4377595 | 5 CAP | 4 | |
| 4377596 | 6 CAP | 16 | |
| 4965282 | 7 BLOCK AS | 2 | |
| 4377598 | 8 BLOCK-MANIFOLD | 2 | |
| 4377601 | 9 BLOCK-MANIFOLD | 4 | |
| 4391987 | 10 UNION AS | 4 | |
| 6V8734 | UNION | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 4488983 | 11 ADAPTER AS | 16 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3960392 | ADAPTER | 1 | |
| 4512762 | SEAL | 1 | |
| 4510393 | 12 PLUG AS | 8 | |
| 3849219 | PLUG | 1 | |
| 4512762 | SEAL | 1 | |
| 4510428 | 13 ADAPTER AS | 24 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4510427 | ADAPTER | 1 | |
| 4515682 | SEAL | 1 | |
| 4510451 | 14 ADAPTER AS | 2 | |
| 8T5890 | UNION | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 4511739 | 15 ADAPTER AS | 10 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 4696946 | 16 ADAPTER | 12 | |
| 4696947 | 17 ADAPTER | 2 | |
| 4696954 | 18 VALVE AS-CHECK | 24 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4710693 | VALVE-CHECK | 1 | |
| 4733071 | 19 PLUG | 32 | |
| 5076628 | 20 HOSE AS | 2 | |
| 5076669 | 21 HOSE AS | 2 | |
| 5076670 | 22 HOSE AS | 2 | |
| 5076671 | 23 HOSE AS | 2 | |
| 5076672 | 24 HOSE AS | 2 | |
| 5076673 | 25 HOSE AS | 2 | |
| 5076674 | 26 HOSE AS | 2 | |
| 5076675 | 27 HOSE AS | 2 | |
| 5076676 | 28 HOSE AS | 4 | |
| 5076677 | 29 HOSE AS | 2 | |
| 5076680 | 30 HOSE AS | 2 | |
| 5076681 | 31 HOSE AS | 2 | |
| 5076682 | 32 HOSE AS | 2 | |
| 5076683 | 33 HOSE AS | 2 | |
| 5076684 | 34 HOSE AS | 2 | |
| 5076685 | 35 HOSE AS | 4 | |
| 5076686 | 36 HOSE AS | 2 | |
| 5076687 | 37 HOSE AS | 2 | |
| 5076688 | 38 HOSE AS | 2 | |
| 5076689 | 39 HOSE AS | 2 | |
| 5079512 | 40 TUBE AS | 2 | |
| 5079513 | 41 TUBE AS | 1 | |
| 5079514 | 42 TUBE AS | 1 | |
| 1074749 | 43 PLATE | 28 | |
| 1254984 | 44 CLAMP | 4 | |
| 1772215 | 45 STRAP-DUAL CLAMP | 12 | |
| 1964204 | 46 BOLT (M6X1X40-MM) | 8 | |
| 2322496 | 47 CLAMP-HALF | 64 | |
| 2977976 | 48 ELBOW AS | 2 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3309720 | 49 REDUCER AS | 4 | |
| 6V8944 | REDUCER | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3353971 | 50 TEE AS | 4 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 3526510 | 51 TEE AS | 2 | |
| 6V8792 | TEE-FACE SEAL | 1 | |
| 2287093 | SEAL-O-RING | 3 | |
| 4357441 | 52 PLATE-COVER | 6 | |
| 6V5220 | 53 BOLT (M8X1.25X65-MM) | 16 | |
| 6V8557 | 54 NUT-FACE SEAL (1-7/16-12-THD) | 4 | |
| 6V9168 | 55 NUT (11/16-16-THD) | 12 | |
| 6V9833 | 56 CAP | 2 | |
| 7X2533 | 57 BOLT (M6X1X35-MM) | 56 | |
| 8T4224 | 58 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 8T6466 | 59 BOLT (M10X1.5X60-MM) | 12 | |
| 9U7123 | 60 CAP | 10 |
