System And Components
349-1527 COVER GP-VALVE MECHANISMS/N SYE1-UP
Group No: 349-1527 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N8109 | 1 CLAMP | 1 | |
| 9Y2988 | 2 BREATHER AS (CRANKCASE) | 1 | |
| 2274531 | 3 CAP AS-ENGINE OIL FILLER | 1 | |
| 7F8268 | SEAL-O-RING | 1 | |
| 2444500 | 4 SPRING | 10 | |
| 2600113 | 5 SEAL-VALVE COVER | 1 | |
| 3655169 | 6 ADAPTER | 1 | |
| 3249326 | 7 COVER-VALVE MECHANISM | 1 | |
| 3587347 | 8 BRACKET | 1 | |
| 1310353 | 9 STUD (M8X1.25X82.75-MM) | 2 | |
| 5P7970 | 10 NUT (M8X1.25-THD) | 2 | |
| 5P8244 | 11 WASHER-HARD (12X22.5X2.5-MM THK) | 10 | |
| 6V3831 | 12 SEAL-O-RING | 1 | |
| 0619456 | 13 SEAL-O-RING | 1 | |
| 8T0100 | 14 BOLT (M8X1.25X60-MM) | 8 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 10 |
