Assembly
100%

310-9640 MOUNTING GP-ENGINES/N KCS1-UP; LJY1-UP

Group No: 310-9640 · Commonality
Part NumberPart NameQty
10993291 WASHER (21.5X120X8-MM THK)2
10994372 WASHER (24.5X135X12-MM THK)2
11899303 SUPPORT AS1
4512184NUT (M20X2.5-THD)1
13987364 MOUNT-FLEXIBLE (LOWER)2
13987375 MOUNT-FLEXIBLE (UPPER)2
13988736 SUPPORT AS2
4512185NUT (M24X3-THD)1
26662987 MOUNT-RUBBER (LOWER)2
26662998 MOUNT-RUBBER (UPPER)2
36866799 SUPPORT AS1
4512184NUT (M20X2.5-THD)1
324439410 BRACKET AS1
324439711 BRACKET AS1
447171212 BOLT (M20X2.5X130-MM)2
447172113 BOLT (M24X3X160-MM)2
451218814 WASHER-HARD (26X50X8-MM THK)2
451217615 WASHER-HARD (22X35X3.5-MM THK)4
451217716 WASHER-HARD (26X44X4-MM THK)2
447170917 BOLT (M16X2X45-MM)8
451217518 WASHER-HARD (17.5X30X3.5-MM THK)8
