344-9102 LINES GP-FUEL INJECTIONS/N SYE1-UP

Group No: 344-9102 · Commonality
Part NumberPart NameQty
13103531 STUD (M8X1.25X82.75-MM)3
32595502 STUD (M8X1.25X57-MM)2
32595513 STUD (M8X1.25X66.5-MM)1
42343594 TUBE AS-FUEL3
42343605 TUBE AS-FUEL2
34374606 CLAMP AS8
42343587 TUBE AS-FUEL1
37122568 TUBE AS-FUEL1
42284089 RAIL GP-FUEL1
6V822510 NUT (M6X1-THD)3
8T064011 BOLT (M6X1X30-MM)1
9M197412 WASHER-HARD (8.8X16X2-MM THK)3
9X826713 WASHER (6.6X12X2-MM THK)4
4286098KIT-FUEL LINES2
4286097KIT-FUEL LINES1
4286096KIT-FUEL LINES1
