System And Components
497-6211 PUMP GP-FUEL TRANSFERS/N KCS10001-UP; LJY10001-UP
Group No: 497-6211 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 0065707 | 2 ELBOW-PIPE | 1 | |
| 1114839 | 3 STRAP | 2 | |
| 1965650 | 4 SWITCH AS (REFUELING PUMP RELAY) | 1 | |
| 1976076 | NUT (M30X1-THD) | 1 | |
| 1976082 | BOOT | 1 | |
| 2006345 | 5 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 3685216 | 7 PUMP GP-FUEL TRANSFER | 1 | |
| 3685219 | 8 CONNECTOR-HOSE | 1 | |
| 4610505 | 9 PLATE AS | 1 | |
| 5014104 | 10 PLATE | 1 | |
| 5014186 | 11 VALVE GP-REFUELING (FOOT) | 1 | |
| 1114838 | 12 CLIP | 2 | |
| 2042281 | 13 STRAP-CABLE | 2 | |
| 2S1647 | 14 GROMMET | 1 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4183 | 17 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9M7958 | 20 CLAMP-HOSE | 4 | |
| 4571157 | 21 HOSE (415-CM) | ||
| 4571157 | 21A HOSE (55-CM) |
