System And Components
319-1175 LIGHTING GP-BOOM -REACHS/N KCS1-UP; LJY1-UP
Group No: 319-1175 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7I2673 | 1 STRAP-CABLE | 2 | |
| 1114836 | 2 CLIP | 10 | |
| 1114837 | 3 CLIP | 1 | |
| 1160118 | 4 CLIP | 1 | |
| 1343284 | 5 BRACKET | 2 | |
| 1532521 | 6 LAMP GP-FLOOD (24-VOLT) | 2 | |
| 3508395 | 7 HARNESS AS-LIGHTING (BOOM) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 4 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 6V3265 | 8 CLIP | 2 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 3 | |
| 4532834 | 11 BOLT (M16X2X30-MM) | 2 | |
| 4512175 | 12 WASHER-HARD (17.5X30X3.5-MM THK) | 2 | |
| 1757141 | 13 NUT-HEX FLANGE (M10X1.5-THD) | 11 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 7 |
