System And Components
385-1334 SENSOR & MTG GP-SOOTS/N KCS1-UP; LJY1-UP
Group No: 385-1334 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 3 | |
| 3264516 | 2 TIE-CABLE | 9 | |
| 4415127 | 3 SENSOR AS-NITROGEN OXIDE (ENGINE OUTPUT) | 1 | |
| 4415128 | 4 SENSOR AS-NITROGEN OXIDE (EXHAUST PIPE OUT) | 1 | |
| 4793165 | 5 PLATE AS | 1 | |
| 3966211 | 6 GROMMET | 1 | |
| 4191129 | 7 PLATE AS | 1 | |
| 1013625 | 8 CLIP (LADDER) | 5 | |
| 1325789 | 9 CLIP (LADDER) | 1 | |
| 2856393 | 10 CLIP (LADDER) | 2 | |
| 4P7581 | 11 CLIP (LADDER) | 2 | |
| 5C9553 | 12 BOLT (M6X1X16-MM) | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4138 | 16 BOLT (M6X1X20-MM) | 2 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 4 |
