System And Components
380-5463 WIRING GP-CEMS/N KCS1-UP; LJY1-UP
Group No: 380-5463 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2743780 | 1 CAP-SEAL | 1 | |
| 2743781 | 2 CAP-SEAL | 1 | |
| 8T4908 | 3 BOLT (M8X1.25X25-MM) | 3 | |
| 2956237 | 4 WIRE AS-IGNITION | 1 | |
| 3150225 | 5 CLAMP-WIRE | 1 | |
| 4882652 | 6 SLEEVE | 10 | |
| 3479210 | 7 SPACER (11X26X60-MM THK) | 4 | |
| 3524755 | 8 WIRE AS (NOZZLE HEATER) | 1 | |
| 3553322 | 9 BRACKET | 1 | |
| 3638155 | 10 BRACKET | 1 | |
| 3648334 | 11 PLATE AS | 1 | |
| 6V6716 | RIVET-TRUSS HEAD | 2 | |
| 1091645 | CLIP | 1 | |
| 3665692 | 12 BRACKET | 1 | |
| 3685011 | 13 BRACKET | 1 | |
| 3704373 | 14 CLIP | 4 | |
| 3735283 | 15 SENSOR GP-TEMPERATURE (SELECTIVE CATALYTIC REDUCTION) | 1 | |
| 3744768 | 16 SENSOR GP-TEMPERATURE (DUAL SENSOR- DPF, FLAME DETECT) | 1 | |
| 3805464 | 17 WIRING GP-CEM | 1 | |
| 8T4138 | 18 BOLT (M6X1X20-MM) | 2 | |
| 8T4177 | 19 BOLT (M8X1.25X90-MM) | 1 | |
| 2261388 | 20 SPACER (9X20X10-MM THK) | 2 | |
| 2674211 | 21 SPACER (8.8X16X15-MM THK) | 1 | |
| 2856393 | 22 CLIP (LADDER) | 2 | |
| 2856395 | 23 CLIP (LADDER) | 1 | |
| 8T4224 | 24 WASHER-HARD (8.8X16X2-MM THK) | 15 | |
| 0993649 | 25 BOLT (M8X1.25X40-MM) | 3 | |
| 8T4189 | 26 BOLT (M8X1.25X20-MM) | 2 | |
| 2901993 | 27 STRAP-CABLE | 12 | |
| 8T3647 | 28 BOLT (M8X1.25X80-MM) | 3 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 2 | |
| 8T4199 | 30 BOLT (M8X1.25X12-MM) | 1 | |
| 5C9553 | 31 BOLT (M6X1X16-MM) | 1 | |
| 3639707 | 32 CLIP | 1 | |
| 4P5918 | 33 CLIP | 1 | |
| 1622165 | 34 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 3S2093 | 35 STRAP-CABLE | 7 | |
| 7K1181 | 36 STRAP-CABLE | 18 |
