System And Components
377-8188 WIRING GP-CHASSIS -REFUELING PUMPS/N KCS1-UP; LJY1-UP
Group No: 377-8188 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 28 | |
| 4P7581 | 2 CLIP (LADDER) | 2 | |
| 7K1181 | 3 STRAP-CABLE | 10 | |
| 8T4121 | 4 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 5 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4179 | 6 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9X3495 | 8 CLIP AS | 1 | |
| 4186596 | 9 SWITCH AS-LIQUID LEVEL (REFUELING) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3245761 | 10 COVER AS | 1 | |
| 1211029 | CLIP | 1 | |
| 3606269 | 11 HARNESS AS-FUEL TANK (REFUELING PUMP) | 1 | |
| 3508388 | 12 SPACER (11X25X65-MM THK) | 1 | |
| 1325789 | 13 CLIP (LADDER) | 1 | |
| 8T4178 | 14 BOLT (M10X1.5X90-MM) | 1 | |
| 4389950 | 15 HARNESS AS-CHASSIS | 1 |
