System And Components
502-6773 WIRING GP-FRONTS/N KCS1-UP; LJY1-UP
Group No: 502-6773 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 23 | |
| 7K1181 | 2 STRAP-CABLE | 5 | |
| 1160118 | 3 CLIP | 1 | |
| 4767324 | 4 HARNESS AS-FRONT (STICK) | 1 | |
| 3E3390 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 3E5165 | CAP AS-PROTECTION | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(25-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 8 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 8 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 2532695 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 3034244 | RECEPTACLE AS-CONNECTOR | 1 | |
| 5049444 | 5 HARNESS AS-SENSOR (GRADE CONTROL, STICK) | 1 | |
| 4P7581 | 6 CLIP (LADDER) | 4 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 8 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 9 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4191 | 10 BOLT (M10X1.5X16-MM) | 2 | |
| 3474734 | 11 CLIP | 1 |
