System And Components
388-6676 WIRING GP-VALVES/N KCS1-UP; LJY1-UP
Group No: 388-6676 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 7I2673 | 2 STRAP-CABLE | 2 | |
| 7K1181 | 3 STRAP-CABLE | 13 | |
| 3423156 | 4 BRACKET AS-VALVE | 1 | |
| 4378452 | 5 HARNESS AS-VALVE | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 10 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 14 | |
| 3S2093 | STRAP-CABLE | 6 | |
| 8T8737 | PLUG-SEAL | 5 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(30-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 6 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 4450705 | SEAL-CONNECTOR | 1 | |
| 2434508 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 1325789 | 6 CLIP (LADDER) | 7 | |
| 4P7581 | 7 CLIP (LADDER) | 5 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4191 | 9 BOLT (M10X1.5X16-MM) | 13 | |
| 8T4199 | 10 BOLT (M8X1.25X12-MM) | 1 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 1 |
