System And Components
473-4159 FRAME GP-MOUNTING -EXHAUSTS/N KCS1-UP; LJY1-UP
Group No: 473-4159 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0118 | 1 HOOK AS | 1 | |
| 2622603 | 2 SPACER (13.5X30X16-MM THK) | 16 | |
| 2983111 | 3 HANDLE AS | 1 | |
| 3272884 | 4 BRACKET AS | 1 | |
| 3272886 | 5 STRIKER AS | 1 | |
| 3334417 | 7 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3334419 | LINER | 1 | |
| 3432465 | 8 BUMPER | 2 | |
| 4734166 | 9 SUPPORT AS | 1 | |
| 4734161 | 10 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 4382496 | 11 SHEET AS | 1 | |
| 4442752 | LINER | 1 | |
| 4719825 | 12 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 7 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 1358575 | 13 BOLT AS | 11 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4184 | 18 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4189 | 19 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4196 | 20 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 |
