System And Components
Assembly
100%

383-2374 FRAME GP-UPPERS/N KCS1-UP; LJY1-UP

Group No: 383-2374 · Commonality
Part NumberPart NameQty
09300901 SHIM (1-MM THK)4
09303642 SPACER (103X140X12-MM THK)2
11754353 PIN AS2
13324274 SHIM (0.5-MM THK)2
16614885 SHIM (2-MM THK)4
17763156 PLUG20
21228417 SHIM (2-MM THK)3
32409388 PLATE1
32409419 PIN AS1
394578810 FRAME AS-UPPER1
7Y111310A BOSS1
387344110B STEP AS1
436026211 SHIM (3-MM THK)2
096646712 WASHER (22X60X8-MM THK)2
451217613 WASHER-HARD (22X35X3.5-MM THK)2
453284414 BOLT (M20X2.5X30-MM)2
447170915 BOLT (M16X2X45-MM)2
451217516 WASHER-HARD (17.5X30X3.5-MM THK)2
3506474PLATE-SKIRT (1100-MM)1
3506475PLATE-SKIRT (2000-MM)1
