296-6308 GEAR & BEARING GP-SWINGS/N KCS1-UP
Group No: 296-6308 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K9243 | 1 ELBOW-FLARED | 4 | |
| 3333089 | 2 PLUG | 11 | |
| 7Y1647 | 3 GASKET | 1 | |
| 7Y1650 | 4 CLAMP-HOSE | 1 | |
| 3531660 | 5 BOLT (M24X3X180-MM) | 15 | |
| 1121531 | 6 BOLT (M24X3X120-MM) | 46 | |
| 1994523 | 7 TUBE AS (RH) | 1 | |
| 1994524 | 8 TUBE AS (LH) | 1 | |
| 2276105 | 9 BOOT | 1 | |
| 2276106 | 10 RETAINER | 1 | |
| 3936550 | 11 GEAR & BEARING GP-SWING | 1 | |
| 0930020 | 12 SPACER (25X44X6-MM THK) | 46 | |
| 1416373 | 13 BOLT (M24X3X150-MM) | 31 | |
| 1484703 | 14 COVER | 1 | |
| 1484704 | 15 GASKET | 1 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4N9170 | 17 CLIP | 4 | |
| 7Y1095 | 18 DOWEL | 1 | |
| 7Y1507 | 19 SPACER (24.5X44X43-MM THK) | 46 | |
| 7Y1648 | 20 STRIP | 1 | |
| 4533454 | 21 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 4553798 | 22 BOLT (M10X1.5X25-MM) | 12 | |
| 4578759 | 23 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4199 | 24 BOLT (M8X1.25X12-MM) | 4 | |
| 1U8846 | SEALANT-GASKET |
